X-431 Throttle V - Professional Diagnostic Scan Tool
Couldn't load pickup availability
Our team uses these tools in real shops. Questions about compatibility, software activation, or whether this is the right fit for your workflow — call, email, or book a free video consult.
Ask an expert
X-431 Throttle V
The Launch X-431 Throttle V stands as the most powerful diagnostic tablet in the X-431 series, delivering lightning-fast performance, extensive vehicle coverage, and advanced diagnostic capabilities. Engineered for efficiency and precision, this tool is ideal for high-volume repair shops and mobile technicians seeking OE-level diagnostics and comprehensive repair solutions.
Features:
-
High-Performance Hardware: Equipped with a 2.0GHz octa-core processor, 12GB RAM, and 512GB storage, ensuring seamless multitasking and rapid data processing.
- 13.6" 2K HD Touchscreen: Features a 2560x1600 resolution display for clear visualization of diagnostic data and intuitive navigation.
- Comprehensive Vehicle Coverage: Supports diagnostics for passenger vehicles, commercial trucks, motorcycles, and new-energy EV systems, providing versatility across various vehicle types.
- Advanced Diagnostic Protocols: Includes support for CAN FD, DoIP, J2534, D-PDU, and RP1210 protocols, ensuring compatibility with modern vehicle communication standards.
- Smart Topology Mapping: Offers a visual representation of all vehicle systems in a single diagram, facilitating faster and more accurate diagnostics.
- Remote Diagnostics: Enables technicians to perform diagnostics remotely, enhancing service efficiency and flexibility.
- Modular Expansion Support: Compatible with Launch’s full line of optional modules, including TPMS tools, ADAS calibration equipment, battery testers, and key programming devices.
- Access to Repair Information: Provides access to X-431 FIX and CODEASSIST (subscription-based), offering verified DTC repair guides and wiring diagrams to streamline the repair process.
Specs:
- Operating System: Android 13
- Processor: 2.0GHz Octa-core
- Memory: 12GB RAM
- Storage: 512GB ROM
- Display: 13.6" 2K HD Touchscreen (2560x1600 resolution)
- Battery: 9,360 mAh at 7.6V/71.1Wh
- Wi-Fi: Dual Band (2.4GHz & 5GHz)
- Camera: Rear 20MP, Front 8MP
- Interfaces: Type C, Type A, DC IN, Micro SD, Mini HDMI
- Dimensions: 14.83 x 9.69 x 1.38 inches
Package Contents:
- X-431 Throttle V Tablet
- SmartLink V3.0
- Ethernet Cable (15m)
- OBDII Cable
- Power Adapter
- Type A to Type B Data Cable
- Type C to Type C USB Cable
- HDMI Cable
- Universal Pin Envelope
- Quick Start Guide
